Heavy Duty Industrial Ventilation Fan Max Airflow 45000m³/h Greenhouse Circulation Fans

Heavy Duty Industrial Ventilation Fan Max Airflow 45000m³/h Greenhouse Circulation Fans

45000m³/h Industrial Ventilation Fan

Greenhouse Circulation Fans

Heavy Duty Industrial Ventilation Fan

원래 장소:

중국

브랜드 이름:

Terrui

인증:

CE

모델 번호:

YDA048DECKA0

연락주세요
인용문을 요구하세요
제품 상세정보
제품명:
48'' 배기팬
크기:
1460*1460*580mm
블레이드 직경:
48''/1.22m
설치:
벽의 프레임에 나사로 고정
공기 부피/W:
52.9m³/h
현재의:
1.7a
회전 속도:
460r/min(20%-100% 속도 제어)
힘:
3Φ/380V/50HZ
보호 수준:
IP55
프레임 재질:
고강도 유리섬유
맥스 기류:
45000m3/h
모터:
외부 회전자 영구 자석 브러시리스 DC 모터
유형:
산업용 배기가스 팬
강조하다:

45000m³/h Industrial Ventilation Fan

,

Greenhouse Circulation Fans

,

Heavy Duty Industrial Ventilation Fan

지불과 운송 용어
최소 주문 수량
20
가격
discuss
포장 세부 사항
나무 팔레트
배달 시간
근무일 기준 10일
지불 조건
신용장, 전신환
관련 상품
연락주세요
86-21-64953307
지금 접촉하세요
제품 설명

Energy-Saving Ventilation Fan featuring Advanced Rare Earth EC Motor Technology


Slash your operational costs without sacrificing performance with our ultra-efficient exhaust fan. This unit is powered by advanced Rare Earth EC motor technology, which consumes up to 70% less energy than conventional induction motors. The brushless design eliminates friction losses, ensuring that more power is converted directly into airflow. This translates to significant savings on your electricity bills over the fan's extended lifespan. Smart APP control further enhances efficiency, allowing you to run the fan at optimal speeds and only when necessary, maximizing your return on investment.



Heavy Duty Industrial Ventilation Fan Max Airflow 45000m³/h Greenhouse Circulation Fans 0



Technical Parameters:

Noise

≤70dB

Type

Industrial exhaust fan

Frame Material

High-strength fiberglass

Installation

Screw to the frame on the Wall

Product Model

YDA048DECKA0

Motor

Outer rotor permanent magnet brushless DC motor

Power

3Φ/380V/50Hz

Input power

850w

Max Airflow

45000m³/h

Air Volume/W

52.9m³/h

Rotation Speed

460r/min(20%-100% Speed Control)

Fan Blade Diameter

48''/1.22m

Product Name

48’’/1.2M REFINE Exhaust fan

Protection Level

IP55

Current

1.7A

Frame Size

1460*1460*580mm



This fan is an ideal investment for any facility focused on reducing long-term energy consumption and operating costs. It is perfect for large commercial buildings, data centers, indoor farms, and public institutions where ventilation systems run for extended periods. By upgrading to this energy-saving technology, businesses can not only lower their utility expenses but also contribute to sustainability goals and reduce their carbon footprint, making it a smart choice for both your budget and the environment.
